2023 The Year In Pictures

January 1, 2024 by grahamrob in Broadband, Dark Nebula, Deep Sky Objects, Equipment, Galaxy, General Astronomy, Globular Cluster, Imaging, Mosaic, Narrowband, Nebula, Other, Planetary Nebula, Processing, Samyang 135, Supernova, Widefield Imaging and tagged Aurora Borealis, DSO Imaging, Galaxies, Nebulae | Leave a comment

This Christmas marks the 10^th edition of my astrophotography calendar, consisting of my better images from the previous 12-months, which I produce for myself and members of the family. Wow doesn’t time fly? Based on these images, I also compile a video of the images set to music, which we all watch together before seeing the actual calendar. It’s become something of an occasion and is a great way to present the images, which look wonderful on today’s smart TV’s and is fun to watch and share with the family.

THE CALENDAR

Much longer imaging times (total of more than 145 hours), re-imaging old favourites in new ways and unusual, overlooked, or difficult objects, resulted in a very good 2023 astrophotography year and perhaps the best calendar yet? The calendar for 2024 on YouTube can be viewed by clicking HERE and below is a brief overview of each image. More detailed background information and imaging details for those interested can be found in relevant blogs I posted on this website. The background music is the track Appleshine from Underworld’s album Drift.

COVER	SH2-284: Close-up of April’s image – along the inside of the ring structure are many dark dust pillars and globules, which on the right seem to resemble a hand with a bony finger pointing inwards!
JANUARY	NGC 1333: Nestled within the western area of the Perseus Molecular Cloud, some 1,100 light-years from Earth is the colourful NGC 1333 reflection nebula, one of the closest and most active star-forming regions of the night-sky.
FEBRUARY	Spaghetti Nebula: Straddling the boundary of Taurus and Auriga constellations, is the giant supernova remnant (SNR) Simeis-147. The stellar explosion occurred 40,000 years ago, leaving a rapidly spinning neutron star or pulsar at the core of the now complex and the expanding SNR.
MARCH	Aurora Borealis: Situated just below the Arctic Circle, Iceland is well known both for its geology and views of the Aurora Borealis, which we saw in March on the south coast near Kirkjubaejarkklaustur.
APRIL	SH2-284: A star-forming region of dust and gases, sculpted by radiation and interstellar winds emanating from a young (3 to 4 million years) star cluster located near the centre.
MAY	M3 Globular Cluster*: Consisting of 500,000 stars and over 11 billion years old, M3 is one of150 globular clusters that orbit around the Milky Way Galaxy.
JUNE	*M27 Apple Core Nebula:** A planetary nebula, consisting of a glowing shell of ionized gas ejected from a red giant star in its late stage of life to become a white dwarf. Complex hydrogen (red) and oxygen (blue) fans form around the outer regions, with a pulsar-like beam transecting the nebula.
JULY	Monkey Head Nebula: Located 6,400 light years from Earth in the Orion constellation, the ‘Monkey’ is a so-called emission nebula, where new stars are being created within at a rapid rate.
AUGUST	SH2-115: This widefield image contains a richness of various emission nebulae, centred around the distinctive large blue SH2-115 region. Just to the left of SH2-115 is the small but enigmatic SH2-116 a faint, blue disc thought to be a planetary nebula.
SEPTEMBER	LDN-768 Black Cat Nebula: Close to M27 in the constellation of Vulpecula (“Little Fox”), is a dense region of stars broken-up by dark nebulae to create intriguing shapes. Here strung out from left-to-right, several of the dark nebulae seem to coalesce (visually) to create the form of a black cat.
OCTOBER		SH2-126 Great Lacerta Nebula: On the western edge of the Milky Way in the southern part of Lacerta, is the very large but faint emission nebula SH2-126. The red filament structures stretch over 3 degrees, to the right is the Gecko Nebula, a molecular cloud associated with bright young stars.
NOVEMBER		Flaming Star & Tadpoles Nebula: Two emission nebulae: dust & gas of the Flaming Star (below) combined with red ionized hydrogen gas produces a flame affect. Above, the stellar winds and radiation pressure from hot massive stars creates the Tadpoles ‘wriggling’ away from the centre.
DECEMBER		*M51 Whirlpool Galaxy:** As the smaller galaxy passes behind M51, joint gravitational forces are interacting, resulting in the misalignment of stars and unusually bright blue and pink areas across the Whirlpool galaxy. Their fates are inextricably linked and might eventually merge.
*Footnote:* All images taken from Redhill, Surrey or telescope at a dark sky site in New Mexico, USA shown by an asterisk*
*HAPPY NEW YEAR + CLEAR SKIES FOR 2024*

Icelandic Aurora

April 7, 2023 by grahamrob in Astronomy holidays, DSLR, Earth, Equipment, General Astronomy, Imaging, Solar system, Viewing, Widefield Imaging and tagged Aurora Borealis, Northern Lights | Leave a comment

It’s just over 6-years since my last arctic adventure, which was a trip along the Norwegian coast by ship from Bergen to Kirkenes and back, stopping along the way for deliveries and pick-ups at 30-ports. On that occasion we had good views of the Aurora Borealis whilst at sea somewhere north of the Arctic Circle and with some difficulty, I was eventually able to obtain some images (see below). Standing outside on ther deck at +70^oNorth latitude in February was incredibly cold, making camera operation difficult, whilst the ship’s movement from side-to-side and up-and-down was hardly conducive to photography of the night sky!

This time, I’m just back from circumnavigating the island of Iceland by car from mid to late-March, which is described more fully on my other website Round The Bend here. It was timed to avoid the worst of winter conditions and, with darkness quickly disappearing as Spring / Summer beckoned, maybe still get a chance to see and image the Northern Lights again – this time on terra firma. Despite such planning, severe snow, ice and very strong winds were common for much of the time but, when it was clear the scenery was spectacular and, on a couple of evenings later in the trip, the Aurora Borealis put on a great show.

Situated just below the Arctic Circle, mostly between 64^oand 66^o latitude, Iceland is well known both for its geology and sightings of the Aurora Borealis or Northern Lights. As a geologist, I travelled to Iceland primarily to view the rocks and though it was getting late in the season, I was also keen to see the Aurora again if possible. Given the days of bad weather it was therefore fortunate to have clear skies and good views of the Northern Lights on two separate evenings whilst on the south coast, first at Gerdi near Jökulsárlόn and later just south of Kirkjubaejarkklaustur.

Despite my previous experience, each aurora is different and on this occasion I found using a Canon 700D DSLR mounted on a Gorilla Pod, using a Sigma wide-angle lens set at a focal length of 10mm f3.5 + ISO 3,200 and 10 second exposures generally produced a good image. It seemed that we were on the southern edge of the aurora on the first night at Gerdi (see top of the page), which was therefore weaker but exhibited a striking purple colour (helium). The following night the aurora was much stronger, this time mostly green (oxygen) with red and purple fringing (nitrogen & helium) and generally much more active, resulting in some great views with the naked eye and even better images (see below).

The Flame & Frogs

February 26, 2023 by grahamrob in AstroBin, Deep Sky Objects, Imaging, Nebula, Processing, Widefield Imaging and tagged Auriga | 1 Comment

There’s a lot going on in and around the Auriga constellation and this winter I’ve been mainly imaging in this region, almost exclusively using the Samyang 135 widefield rig. Here with the whopping 7.50^ox 5.67^ofield-of-view this set-up provides, it easily incorporates both emission nebulae IC405, AKA the Flaming Star Nebula and it’s nearby (visually) neighbour IC410, the Tadpoles Nebula, as well as much more.

Hydrogen gas ionized by the central AE Auriga star produces the dominant strong red colour, which combined with the rippling dust and gas lanes that run through the head of IC405 leads to a ‘flame affect’ and thus the nebula’s popular nickname.

The structures in IC410 are illuminated by radiation from the open star cluster NGC1893, located at the centre of the nebula. Hot, massive, young stars abound, especially around Simeis 129 & 130, the two tadpoles. These structures are ‘wriggling away’ from the centre of the nebula, because of the prevailing stellar winds and radiation pressure from the stars in NGC 1893.

This image is the cornerstone of a series of covering a wider area completed during January, which I intend to first present individually before, hopefully, bringing them together as an HOO mosaic later.

This image has been processed as two SHO versions of the Hubble Palette: (i) a basic mix above and (ii) using a dynamic mix ( main cropped image at top-of-the page). Once more I have been impressed by the ability of this small camera lens to produce exceptional detail and colours, but especially here with the starless Ha version of IC410, where the signature features or so-called tadpoles have been captured to great effect (see cropped starless Ha version of IC410 below).

	IMAGING DETAILS
Object	IC 405 The Flaming Star Nebula + IC 410 The Tadpoles Nebula
Constellation	Auriga
Distance	1,500 & 12,000 light-years
Size	Approx. 37’ x 10’ & 40’ x 30’
Apparent Magnitude	+6.0 & +10

Scope / Lens	Samyang 135 @f2.8
Mount	SW AZ-EQ6 GT + EQASCOM computer control & Cartes du Ciel
Guiding	Sky-Watcher EvoGuide 50ED
	+ Starlight Xpress Lodestar X2 camera & PHD2 guiding
Camera	ZWO1600MM-Cool mono CMOS sensor
	FOV 7.5^o x 5.67^o Resolution 5.81”/pix Max. Image Size 4,656 x 3,520 pix
EFW	ZWOx8 EFW & 31mm ZWO LRGB & 7nm Narrowband filters
Capture & Processing	Astro Photography Tool + PHD2 + PixInsight v1.8.9-1
Image Location & Orientation	Centre: RA 05:19:54.329 DEC +33:47:12.699 Right = North Top = East
Exposures	24 x 300 sec Ha & OIII, 18 x 300 sec SII Total Integration Time: 5 hr 30 min
	@ 139 Gain 21 Offset @ -15^oC
Calibration	10 x 300 sec Darks 20 x Flats & Flat Darks
Location & Darkness	Fairvale Observatory – Redhill – Surrey – UK Typically Bortle 5 – 6
Date & Time	2^nd & 9^th January 2023 @ +18.30h
Weather	Approx. <=2^oC RH >=80% 🌙 +80%

Supernova Sensation

February 6, 2023 by grahamrob in Deep Sky Objects, Equipment, Imaging, Narrowband, Samyang 135, SNR, Supernova, Widefield Imaging and tagged Auriga | 2 Comments

Straddling the boundary of Taurus and Auriga, is the giant supernova remnant (SNR) Simeis-147 AKA SH2-240 or the Spaghetti Nebula. It is believed that the stellar explosion that created Simeis-147 occurred some 40,000 years ago, leaving behind a rapidly spinning neutron star or pulsar at the core of the now complex, expanding SNR; the nebulous area has an almost spherical shell consisting of numerous filamentary structures. With an apparent diameter of 3^othe SNR spans some 160 light-years, making it a very large astrophotography target.

I’ve long admired the spectacular SNR Simeis-147 AKA Spaghetti Nebula, which I first imaged with my standard William Optics GT81 scope in January 2022. The outcome (see image below) was pleasing but with the limited FOV it had to be just a nibble of this large object – something of an appetiser you might say. Therefore, ever since putting my Samyang rig together last summer I’ve had only one object in mind with this excellent widefield set-up, which had to be the full menu version of Simeis-147!

Apart from its size, Simeis-147 is very faint, making long exposure time essential, which is always difficult in the UK. However, a rare spell of cold, clear nights this January provided sufficient opportunity over five nights to obtain just over 20-hours integration and a complete image of this truly magnificent SNR.

Notwithstanding the favourable conditions and long-time achieved – a record for me at this location – the faint nature of this object made image processing difficult too. After experimenting, I eventually adopted a tone mapping technique: pre-processing each individual wavelength stack before removing the stars, stretching and processing each of the starless Ha and OIII images before combining using Pixel Math in the ratio: R – (Ha*1.70) + G – (OIII*0.80)+(Ha*0.20) + B- (OIII*0.80)+(Ha*0.20).

With further processing of the HOO starless combination I was able to obtain the desired result of marvellous SNR detail, together with pleasing Ha (red) and especially OIII (blue/green) colours, that altogether with the addition of the stars and some final tweaking produced a striking image with good depth. Moreover, I feel the widefield setting achieved using the Samyang 135 lens produces a striking setting for this fascinating object.

	IMAGING DETAILS
Object	Simeis 147 / SH2-240 AKA Spaghetti Nebula
Constellation	Taurus
Distance	3,000 light-years
Size	Approx. 3.0^o
Apparent Magnitude	Extremely faint

Scope / Lens	Samyang 135 @f2.8
Mount	SW AZ-EQ6 GT + EQASCOM computer control & Cartes du Ciel
Guiding	Sky-Watcher EvoGuide 50ED
	+ Starlight Xpress Lodestar X2 camera & PHD2 guiding
Camera	ZWO1600MM-Cool mono CMOS sensor
	FOV 7.5^o x 5.67^o Resolution 5.81”/pix Max. Image Size 4,656 x 3,520 pix
EFW	ZWOx8 EFW & 31mm ZWO LRGB & 7nm Narrowband filters
Capture & Processing	Astro Photography Tool + PHD2 + PixInsight v1.8.9-1
Image Location & Orientation	Centre: RA 05:41:15.081 DEC +28:05:32.778 Right = North Top = East
Exposures	60 x 600 sec Ha, 62 x 600 sec OIII Total Integration Time: 20 hr 20 min
	@ 139 Gain 21 Offset @ -15^oC
Calibration	5 x 600 sec Darks 20 x Flats & Flat Darks
Location & Darkness	Fairvale Observatory – Redhill – Surrey – UK Typically Bortle 5 – 6
Date & Time	12^th 17^th 18^th 19^th & 21^st January 2023 @ +18.30h
Weather	Approx. <=0^oC RH >=80% 🌙 70% to 0^o New Moon

Feel The Space

December 15, 2022 by grahamrob in Broadband, Deep Sky Objects, Equipment, Galaxy, General Astronomy, Imaging, Widefield Imaging and tagged Andromeda galaxy, DSO Imaging | Leave a comment

As our closest galactic neighbour, I’ve imaged M31 the Andromeda Galaxy five times since beginning my personal astrophotography journey in 2014, each time using my William Optics GT81 apo refractor – first with a DSLR, then a ASI1600mm-Cool and most recently ASI294MM cameras. Andromeda is perhaps the perfect object for my equipment, as it just fits the field-of-view of the aforesaid set-up, which produces something of an up-close-and-personal image of this alluring galaxy. But despite the success of these images, perhaps there’s an alternative view?

This year, I therefore deployed my Samyang 135 + ASI1600MM-Cool rig to capture 6 ½ hours of Andromeda, the result of which shows a whole new perspective of M31. The widefield format of this lens produces greater context than previous images, whilst still obtaining excellent details and colours of the galaxy itself. As a result, this final image (see above) better reveals the galaxy in its true glory deep in space, which in some ways I believe can be more powerful than the more popular close-up renditions of this impressive object (M31 with star reduction applied to the image below).

	IMAGING DETAILS
Object	M31 Andromeda Galaxy
Constellation	Andromeda
Distance	2.5 million light-years
Size	3.2^o x 1^oor 220,000 light-years
Apparent Magnitude	+3.44

Scope / Lens	Samyang 135 @f2.8
Mount	SW AZ-EQ6 GT + EQASCOM computer control & Cartes du Ciel
Guiding	Sky-Watcher EvoGuide 50ED
	+ Starlight Xpress Lodestar X2 camera & PHD2 guiding
Camera	ZWO1600MM-Cool mono CMOS sensor
	FOV 7.5^o x 5.67^o Resolution 5.81”/pix Max. Image Size 4,656 x 3,520 pix
EFW	ZWOx8 EFW & 31mm ZWO LRGB & 7nm Narrowband filters
Capture & Processing	Astro Photography Tool + PHD2 + Deep Sky Stacker, PixInsight v1.8.8-12, Photoshop CC, Topaz Denoise
Image Location & Orientation	Centre: RA 00:42:34.682 DEC +41:14:06.324 Right = North Top = East
Exposures	L 75 x 60 sec, R 27x G27x B22 x 180 sec, Ha 17 x 300 sec Total Integration Time: 6hr 28 min
	@ 139 Gain 21 Offset @ -15^oC
Calibration	Darks, Flats & Flat Darks
Location & Darkness	Fairvale Observatory – Redhill – Surrey – UK Typically Bortle 5-6
Date & Time	17^th, 21^st & 22^nd November 2022 @ +20.00h
Weather	Approx. <=5^oC RH >= 85% 🌙 approx. New Moon

Cygnus Hat-Trick

October 21, 2022 by grahamrob in Deep Sky Objects, General Astronomy, Narrowband, Nebula, Widefield Imaging and tagged Cygnus, DSO Imaging | Leave a comment

The Cygnus constellation is rich in potential astrophotography targets and since the return of astronomical darkness I’ve bagged three objects from this area with my new widefield Samyang 135 rig: Cygnus Loop, Sadr Region & Crescent Nebula, and the Western Veil & Pickering’s Triangle. As the Cygnus season now draws to a close – in my case disappearing northwards behind my house – I was ready to snap one final Cygnus object using my main William Optics GT81 rig but then looked closer and realised using the Samyang 135 rig with careful framing there was another a more ambitious possibility.

The original object in question was SH2-119 AKA the Clamshell nebula, an emission nebula somewhat overlooked by photographers. Nevertheless, imaged in narrowband there’s plenty of structure to see throughout the nebulosity that makes up the two ‘shells’, whilst the bright magnitude +5 star 68 Cygni might be likened to the pearl at the centre, which would work well with the 81mm William Optics field-of-view. But deploying with care the much wider field-of-view of the Samyang 135 and it’s possible to include the North America and Pelican nebulae as well, just!

With some difficulty (weather) I finally managed to obtain 13-hours integration time over 6-nights, which has resulted in a pleasing SHO image (see main image at the top of the page – below is a dynamic version processed using PI PixelMath), once again demonstrating the capacity of this small but powerful lens. Personally, I find bringing all three objects together within a much larger field-of-view creates greater context, resulting in a more interesting image overall – in football parlance you might call it a hat-trick of nebulae!

	IMAGING DETAILS
Objects	North America Nebula (NGC7000) + Pelican Nebula (IC5070 & IC5067) + Clamshell Nebula (SH2-119)
Constellation	Cygnus
Distance	approx. 2,600 light-years
Size	3.0^o
Apparent Magnitude	approx. +4 to 8

Scope / Lens	Samyang 135 @f2.8
Mount	SW AZ-EQ6 GT + EQASCOM computer control & Cartes du Ciel
Guiding	Sky-Watcher EvoGuide 50ED
	+ Starlight Xpress Lodestar X2 camera & PHD2 guiding
Camera	ZWO1600MM-Cool mono CMOS sensor
	FOV 7.5^o x 5.67^o Resolution 5.81”/pix Max. Image Size 4,656 x 3,520 pix
EFW	ZWOx8 EFW & 31mm ZWO LRGB & 7nm Narrowband filters
Capture & Processing	Astro Photography Tool + PHD2 + Deep Sky Stacker, PixInsight v1.8.8-12, Photoshop CC, Topaz Denoise
Image Location & Orientation	Centre RA 21:06:17.698 DEC +43:58:35.414 Left = North Top =West (original rotated 90^o)
Exposures	Ha 61 x 300 sec, OIII 54 x 300 sec, SII 41 x 300 sec Total Integration Time: 13hr 00 min
	@ 139 Gain 21 Offset @ -10^oC
Calibration	Darks 10 x 300 sec, 15 x Ha OIII SII flats & flat darks
Location & Darkness	Fairvale Observatory – Redhill – Surrey – UK Typically Bortle 5-6
Date & Time	24^th 28^th 29^th September 2^nd 5^th 6^th October 2022 @ +20.30h
Weather	Approx. <=12^oC RH >=75% 🌙 +80%

Shrinking The Universe

September 5, 2022 by grahamrob in Deep Sky Objects, Equipment, Imaging, Narrowband, Nebula, Widefield Imaging and tagged Cygnus | 1 Comment

Hitherto, most of my astrophotography has concentrated on a variety of specific objects that work within the 2.65^o x 2.0^o field-of-view provided by the combination of my William Optics GT81 refractor and ZWO ASI1600MM-Cool camera. After recently pairing the aforesaid ZWO mono camera with a Samyang 135 lens (often marketed elsewhere as the Rokinon 135) my astrophotography world has expanded dramatically to an enormous 7.50^o x 5.67^o, some x8 larger than before. As a result, this excellent lens that also captures great detail, provides new opportunities to image some of the very large features that abound throughout the Universe without having to resort to a mosaic imaging; this a great advantage when working in UK weather conditions which usually provides less imaging time than required.

Above, Cygnus-X Region & notable nearby objects: The red box appproximately outlines the image area, which in this plan is presented upside-down compared to the main image. The numerous red shapes define the location of the HII objects that make up the DWB catalogue (19 is the Crescent nebula). Just beyond to the left is the North America Nebula (NGC7000) and below the SNR Cygnus Loop, AKA the Veil Nebula (NGC 6960 & 6992).

In this case I chose to frame the image in such a way as to encompass some familiar objects, such as the Butterfly Nebula (IC1318) and the Crescent Nebula (NGC6888) anchored by Sadr, the yellow-white supergiant star that stands out from within the very large Cygnus-X region. Processed here in HOO, with 6-hours integration time and full calibration (darks, flats & flat darks), the final image provides a magnificent view of this large, interesting region that augurs well for future widefield imaging with this new rig. I’m particulalry intrigued by the bluish feature at about 8.0 o’clock of the Crescent Nebula, which I now believe to be associated with WR-134: a bubble-like structure some 50 light-years in diameter consisting of OIII rich light formed by an intense wind emanating from the Wolf-Rayet star at it’s centre. The breadth of view it provides can encompass myriad of objects in exceptional detail, thereby providing a wider context that is simply awe-inspiring to see – it’s just like shrinking the Universe!

	IMAGING DETAILS
Object	Sadr Region
Constellation	Cygnus
Distance	+5,000 light-years
Size	Full FOV – see below
Apparent Magnitude	+/- 7.0

Scope / Lens	Samyang 135 @f2.8
Mount	SW AZ-EQ6 GT + EQASCOM computer control & Cartes du Ciel
Guiding	Sky-Watcher EvoGuide 50ED
	+ Starlight Xpress Lodestar X2 camera & PHD2 guiding
Camera	ZWO1600MM-Cool mono CMOS sensor
	FOV 7.5^o x 5.67^o Resolution 5.81”/pix Max. Image Size 4,656 x 3,520 pix
EFW	ZWOx8 EFW & 31mm ZWO LRGB & 7nm Narrowband filters
Capture & Processing	Astro Photography Tool + PHD2 + Deep Sky Stacker, PixInsight v1.8.8-12, Photoshop CC, Topaz Denoise
Image Location & Orientation	Centre RA 20:16:40.452 DEC +38:50:14.404 Right = North Top = East
Exposures	36 x 500 sec Ha, 36 x 300 sec OIII Total Integration Time: 6hr
	@ 139 Gain 21 Offset @ -10^oC
Calibration	5 x 300 sec Darks 15 x Flats & Flat Darks
Location & Darkness	Fairvale Observatory – Redhill – Surrey – UK Typically Bortle 5-6
Date & Time	10^th & 12^h August 2022 @ +22.00h
Weather	Approx. 25^oC RH 50 – 60% 🌙 100% Full Moon

A New Perspective

August 19, 2022 by grahamrob in Deep Sky Objects, Equipment, General Astronomy, Imaging, Narrowband, Supernova, Widefield Imaging and tagged Cygnus, DSO Imaging | 2 Comments

It’s been nearly two years since acquiring my Samyang 135 lens but since then it’s unfortunately only had limited use in combination with my modded 550D DSLR. Whilst impressed with the results from this set-up, my main objective has always been to combine it with my ASI1600 mono camera for some serious widefield astrophotography but as that was being used with my William Optics refractor it just didn’t happen, until now. After upgrading to a ASI294MM Pro camera in May, at last I was finally able spend the early part of this summer working on a new Samyang 135 + ASI1600 rig and now that astronomical darkness is (just) back I recently managed to catch a few photons with this new set-up of the large SNR Cygnus Loop.

I originally purchased a x2-ring Astrokraken 3D-printed clamping system for the lens + DSLR combination from Philippe in France but since then he’s tweaked the design. In particular x3 built-in M4 nuts have been incorporated on either side of each of the two main lens clamping rings, for the purpose of attaching ancillary equipment, which for me has been a game changer. I therefore bought a new x3-ring Astrokraken bracket, with the said bolt holes, around which to build my new rig:

The two main clamping rings that hold the lens have a shoe immediately above the lens, to which I’ve fitted a Sky-Watcher EvoGuide 50ED guidescope (not yet working), with the rear third ring holding the ASI1600 mono camera & EFW.
I swapped the Canon lens bayonet adapter for a bespoke M42 screw adapter, in order to ensure a more secure attachment, thus reducing any potential lens-camera movement at this critical point of the image train.
I’m continuing to use the excellent Astrokraken micro-focuser, which consists of a ring that clamps onto to the lens’ focus ring, with two small bolts above that make contact with either side of the guidescope shoe, so that when turned the focus ring can be adjusted either way to obtain focus, which is then locked when completed. So far I’ve found the micro-focuser to work very well with this lens, assisted by the addition of an Astrokraken Bahtinov mask which is inserted into the front of the lens casing.
Using this lens with the ZWO ASI1600MM-Cool camera and EFW, the backfocus guideline is 44mm, which I was able to achieve by adding an Altair T2 variable locking extension ring set to 17.5mm = 44mm minus 26.5 (camera + EFW).
With my Chroma filters now being used with the new ASI294MM Pro camera, I purchased another ZWO 31mm x8 EFW and brought my ZWO 31mm filters out of retirement.
Finally, using the new M4 nut holes I’ve added a Baader Skysurfer III RDF on the left-hand side of the Astrokraken bracket system to help with sky navigation and framing.

After bolting the Astrokraken with the lens, camera and said components to a Losmandy plate it makes a very nice compact rig, that is easy to handle and store. Notwithstanding, as they say – the proof of the pudding is in the eating: SEE top-of-the page for original image & below for 50% crop.

Whilst the recent heatwave produced clear skies, it was far from ideal here for astronomy and was further hampered by a full moon. However, with only just over two hours integration time and a few Dark calibration files, I’m still impressed with the outcome of this quite amazing lens. It is very pleasing to capture the entire Cygnus Loop comfortably sitting within the lens’ FOV – for information on this FOV and comparisons go to this previous WTSM blog HERE. For me context is important with astrophotography and in this regard the astronomical perspective this lens produces is outstanding, no wonder it is so popular. I just love working with this FOV and can’t wait for better conditions for greater integration time and more widefield targets to point this wicked little lens at.

	IMAGING DETAILS
Object	Cygnus Loop
Constellation	Cygnus
Distance	2,400 light-years
Size	3.0^o
Apparent Magnitude	+7.0

Scope / Lens	Samyang 135 @f2.8
Mount	SW AZ-EQ6 GT + EQASCOM computer control & Cartes du Ciel
Guiding – Not Used	Sky-Watcher EvoGuide 50ED
	+ Starlight Xpress Lodestar X2 camera & PHD2 guiding
Camera	ZWO1600MM-Cool mono CMOS sensor
	FOV 7.5^o x 5.67^o Resolution 5.81”/pix Max. Image Size 4,656 x 3,520 pix
EFW	ZWOx8 EFW & 31mm ZWO LRGB & 7nm Narrowband filters
Capture & Processing	Astro Photography Tool + PHD2 + Deep Sky Stacker, PixInsight v1.8.8-12, Photoshop CC, Topaz Denoise
Image Location & Orientation	Centre RA 20:52:28.01 DEC +31:14:56.186 Right = North Top = East
Exposures	27 x 180 sec Ha, 20 x 180 sec OIII Total Integration Time: 4hr 21 min
	@ 139 Gain 21 Offset @ -10^oC
Calibration	5 x 180 sec Darks
Location & Darkness	Fairvale Observatory – Redhill – Surrey – UK Typically Bortle 5-6
Date & Time	9^th & 10^h August 2022 @ +22.00h
Weather	Approx. 27^oC RH <=50% 🌙 96% Full Moon

Veil Of Darkness

June 10, 2022 by grahamrob in Broadband, Dark Nebula, Deep Sky Objects, Imaging, Widefield Imaging and tagged Milky Way, Pleiades, Taurus Constellation | Leave a comment

Just northeast of the Pleiades star cluster within the northern Milky Way, lies the dark region of the Taurus Molecular Cloud (TMC), which at 430 light years is the nearest star-forming region to Earth. Consisting of hundreds of solar masses of primordial hydrogen and helium gas, as well as heavier elements, this vast area of dense stardust obscures almost all light from behind. As such it forms an alluring target for astrophotography, with the complex rift-like dark structure of the TMC set against the broad starry background of the Taurus constellation.

Notwithstanding, perhaps because of the more popular objects that abound throughout its neighbour the Orion constellation, the TMC is somewhat neglected by astronomers; to be fair the TMC is also a more challenging imaging target than many of those found in Orion. Early this year, for the first time I decided to image the dark nebula Barnard 22, an iconic section of the TMC formed by a complex mass of dark stardust that appears to hang within the vast surrounding starfield.

Approaching the new moon in late January I obtained almost 11 hours of LRGB subs, though sadly was unable to incorporate another 6-hours of 10-minute luminance exposures which proved to be too bright to use: note-to-self – check settings for new objects before embarking on long imaging programme! To achieve a balance between the large black smudge that is B 22 and the brilliance of the surrounding stars processing was tricky but the final outcome satisfying. Also noteworthy in the image, just off centre is the small flame-shaped reflection nebula IC 2087, the light from which just manages to emerge from behind the otherwise dominant, though beguiling form of Barnard 22, which like night itself seems to casts a dark veil over the cosmos.

	IMAGING DETAILS
Objects	Barnard 22 dark nebula & IC 2087 reflection nebula
Constellation	Taurus
Distance	Approx.. 430 light years
Size	–
Apparent Magnitude	Varies

Scope	William Optics GT81 + Focal Reducer FL 382mm f4.72
Mount	SW AZ-EQ6 GT + EQASCOM computer control & Cartes du Ciel
Guiding	William Optics 50mm guide scope
	+ Starlight Xpress Lodestar X2 camera & PHD2 guiding
Camera	ZWO1600MM-Cool mono CMOS sensor
	FOV 2.65^o x 2.0^o Resolution 2.05”/pix Max. image size 4,656 x 3,520 pix
EFW	ZWOx8 EFW & 31mm Chroma LRGB filters
Capture & Processing	Astro Photography Tool + PHD2 + Deep Sky Stacker, PixInsight v1.8.8-12, Photoshop CC, Topaz AI DeNoise
Image Location & Orientation	Centre RA 04:39:00.365 DEC +26:00:13.426 Lower Left = North
Exposures	120 x 180 sec L, 19 x 300 sec R, 20 x 300 sec G & B Total Integration Time: 10hr 55 min
	@ 139 Gain 21 Offset @ -20^oC
Calibration	10 x 60 sec Darks 15 x LRGB Flats & Dark Flats @ ADU 25,000
Location & Darkness	Fairvale Observatory – Redhill – Surrey – UK Typically Bortle 5-6
Date & Time	27^th 29^th 31^st January + 4^th & 6^th February 2022 @ +18.30h
Weather	Approx. <4^oC RH >=75% 🌙 around New Moon

2021 The Year In Pictures

January 1, 2022 by grahamrob in AstroBin, Broadband, Dark Nebula, Deep Sky Objects, Galaxy, General Astronomy, Globular Cluster, Imaging, Narrowband, Nebula, Processing, Star Cluster, Supernova, Widefield Imaging and tagged Astrophotography, DSO Imaging | Leave a comment

Every year since 2014 I’ve published a retrospective blog of my astrophotgraphy year just ending called Reflections. It’s been a useful task that enables me to bring together the best and sometimes the worst of my images, in order to consider the good and bad points + progress made + set some objectives for the coming year. Eight years on, after which I believe I’ve now reached at least a respectable level of imaging and processing, I’ve decided to stop this format for the time being.

Notwithstanding, at this time of the year I also produce an astrophotography calendar for members of my family, which consists of the better images from the year just ending; I think they like them and certainly all use the calendar during the coming year. Moreover, I also recently started to compile a video of the said calendar images set to appropriate music, which we all watch together prior to seeing the actual calendar. It’s a great way to present the images, which look really stunning on today’s large Smart TV’s and is fun to watch with the family too.

The video for this last year 2021 can be viewed on YouTube HERE and below is a brief very general overview of each image. More detailed background information and imaging details for those interested can be found in relevant blogs posted on this site during the past year.

2022 CALENDAR

A new set of filters, improved processing techniques and access to data from a telescope at a dark sky site in New Mexico, USA (shown by an asterisk *) contributed to an exciting astrophotography year in 2021.

FRONT COVER	The Carnival of Animals: Special processing of the inner region of the Rosette Nebula highlights the ‘animals’ or Bok Globules – clouds of dust undergoing gravitational collapse as part of the process of new star formation.
JANUARY	LDN-1250 Dark Nebula*: Dark or absorption nebulae are a type of interstellar cloud which are so dense they obscure or absorb visible light emitted from objects behind or within and thereby contrast with the general light flux of the Universe as dark areas.
FEBRUARY	CTB-1 Supernova Remnant*: The overall structure of this supernova remnant is that of a circular shell, with a conspicuous rupture towards the north (lower right of image). The main red Ha-shell is composed of multiple interlocking filament limbs, with a blue / green OIII arc along one side.
MARCH	Jellyfish Nebula: Locatedin the Gemini constellation some 5,000 light years from Earth, this is a remnant of a supernova that took place during the past 30,000 years. With a diameter of 70 light-years, the object is visually speaking nearly twice the size of a full moon.
APRIL	Markarian’s Chain: The Virgo cluster consists of more than 2,000 galaxies, within which Markarian’s Chain forms a J-curve string of bright galaxies that share a common motion through space.
MAY	*M13 Great Globular Cluster of Hercules:** Consisting of several hundred thousand stars and 145 light-years in diameter, M13 is considered to be the finest cluster in the Northern Hemisphere.
JUNE	*Cave Nebula**: Located along the plane of the Milky Way is the diffuse emission nebula referred to as the Cave Nebula. The Cave at the centre is critically located at the boundary of the Cepheus molecular cloud and the hot, young stars which ionize the surrounding gases to great effect.
JULY	Orion Widefield: Framed around the area of Orion’s Belt, the Horsehead Nebula and the Great Orion Nebula, look hard and the refection nebula M78 can also be seen in the lower left corner.
AUGUST	*Elephant’s Trunk Nebula**: A very large emission nebula, the so-called Elephant’s Trunk Nebula is rightly viewed as one of astrophotography’s most iconic images. The ‘trunk’ itself dominates the centre of this image and is illuminated from behind by a bright star forming region.
SEPTEMBER	M31 Andromeda Galaxy: The full benefit of new filters, improved guiding, clear skies over 6-nights and extensive use of new processing techniques can be seen in my best image yet of Andromeda.
OCTOBER	Butterfly Nebula: Situatedwithin the Orion Arm of the Milky Way is the Gamma Cygni nebula, a diffuse emission nebula surrounding the star Sadr. Either side of the dark rift which divides the image from top to bottom are two large bright areas that together form the so-called Butterfly.
NOVEMBER	M33 Triangulum Galaxy: Like it’s neighbour Andromeda, better data and processing has produced an exciting new image of M33 this year, the red areas highlight Ha-rich star-forming regions
DECEMBER	Flying Bat & Giant Squid Nebula*: This very faint OIII emission nebula Ou4 required an imaging time of 40-hours. For obvious reasons Ou4 has become known as the Giant Squid Nebula which, moreover, lies within the much larger SH2-129 HII emission region or the Flying Bat Nebula.
